Pure rear-stage power amplifier PA2000

Equipped with an advanced and efficient power amplifier circuit, it boasts powerful output and exceptional load capacity. It features one audio input with independently adjustable volume, a voltage output of 70V/100V, a fixed resistance output of 4-16Ω, an output power of 800W, and an output frequency response range of 100~16KHz. The device is equipped with an abnormal operation protection warning function, and corresponding indicator lights will alert when there is an input signal overload, excessive load, high temperature, or line circuit issues, ensuring high reliability. It adopts a 2U standard chassis design with an aluminum alloy panel, offering both aesthetic appeal and practicality. Model: PA2000 Rated output power: 800W Input sensitivity 0dBV Signal-to-noise ratio >80dB Damping coefficient 200:1 Common mode rejection ratio is greater than 90dB Frequency response: 50Hz-15kHz (±3dB) Total harmonic distortion <0.3% at 4W/1kHz Rise rate >15V/microsecond Indicator lights for “Power”, “Clipping”, “Signal”, “Protection”, and “Overtemperature” Protection: power-on, high temperature, DC, short circuit Power Supply: AC220-240V/50-60Hz Power consumption: 750W, 800W Outer packaging dimensions (mm) (L×W×H) 530×440×195 Machine dimensions (mm) (L×W×H) 483×380×88 Gross weight: 19.5kg
800W /2U
1 unit/piece
