SIP network waterproof sound column SIP-40W

· compatible with SIP (RFC3261)
protocol, and can access the
mainstream IP PBX/IMS platforms
• Key features
* networked sound column integrated with networked terminal processors and high-fidelity loudspeakers.
* works across networks.
* can be hooked up anywhere the network reaches.
* supports up to 48kHz sample rate 16bit digital audio stream decoding.
* built-in high-fidelity digital power amplifier, low-power settings.
* can play background music from the system host, emergency paging, alarm signals, etc. .
II. Main functions
1, support hierarchical partition control: using addressable all-digital decoding, receiving superior remote control, according to the different use of environment
to achieve multi-level partition, support the whole area broadcast, partition broadcast, single point broadcast.
2, support network paging: with the paging function of the equipment with the use of calls through this equipment, can clearly play the paging content.
3, support terminal parameters configuration and query: through the serial configuration terminal parameters (server IP, terminal name, Terminal ID) , query
terminal parameters (device ID, Terminal ID, server IP and port number, current network signal value) .
III. Main technical indicators
1. Rated Power: 40W 2. Maximum Power: 50W.
Frequency Response: 20Hz-20kHz.
Signal-to-noise ratio: ≥90dB.
Total harmonic distortion: ≤1% .
Sampling rate: 8kHz-96kHz.
Audio bitrate: 8kbps-320kbps adaptive.
Receive decoded audio format: AAC.
Supported protocols: UDP, TCP/IP.
Power supply: adapter 220v50hz —DC-15V-3A
Operating Temperature: -30 -70 °C.
Working Humidity: 10-90% .
13. Speaker unit: 3×4〞 + 0.5“Treble
14; external dimensions; 155x105x505(mm)
15; weight: 3.3 kg
Easy to install with mounting bracket
